SmallRig Wireless Receiver Motor 3263

SmallRigSKU: SR-3263

Price:
Sale price$149.00 AUD
Stock:
Sold out

Description

SMALLRIG WIRELESS RECEIVER MOTOR 3263

- 0.5N.m peak torque.
- Supports fast charging and 5V-16.8V wide input voltage.
- Independent power supply.
- Quick-release Φ15mm rod clamp.

SmallRig Wireless Receiver Motor 3263, an accessory of the wireless follow focus system, comes with an ultra-low-power 0.52" OLED screen, supports 5V-16.8V wide input voltage, fast charging, and provides 9V/18W and 0.5N.m torque output. It can be powered by Battery Plate (ID: 3777) with NP-F batteries or by USB-C to D-Tap Cable (ID: 3266) and USB-C to DC cable (ID: 3268) with V-Mount batteries. The Wireless Receiver Motor features an open-end rod clamp to avoid any obstacles on Φ15mm rod and allows for handheld and over-the-shoulder shooting for precise follow focus when working with Multi-Functional Wireless Handgrip 391- It connects Wireless Handwheel Controller via control cables (ID: 3325, 2971, 2970, depending on your camera type) for wireless REC start/stops. Also, in cabled mode, it has an ultra-low delay of about 5ms.

IMPORTANT
- Wireless Receiver Motor and Wireless Handwheel Controller can be operated only under the same frequency band and number.
- Calibration is required when the wireless receiver motor reverses rapidly or the handwheel screen displays abnormal location information.
- The two USB-C ports come with different functions.
- For instructions, please refer to the Wireless Follow Focus System User Manual.

SPECIFICATIONS
Product Dimensions: 108.2x 50.1x 32.1mm
Package Dimensions: 121x 104x 44m
Product Weight: 117g±5g
Package Weight: 166g±5g
Material(s): AL6061

COMPATIBILITY
1: Φ49/Φ52/55/58/62/Φ67/72/77/82/86/80/85/90/95/114mm DSLR camera lens and cine lens
2: Φ15 rail support system
3: M0.8 lens and follow focus lens gear ring
4: Incompatible with non-SmallRig wireless follow-focus system
5: Supports fast charging

WHAT IS INCLUDED
1x Wireless Receiver Motor
